FLENDER ZAPEX - Mill the Finished Bore; Table 5-1 Recommended Assigned Fits for Bores with Parallel Key Connection

Assembly
5.1 Preparatory work
26 Edition 09/2022 M3560-02en
5.1.1 Mill the finished bore5.1 Preparatory work
The diameter of the finished bore depends on the shaft used.
Recommended assigned fits
In the following table you can find the recommended assigned fits for bores with a parallel
key connection.
Description Interference fit
Shaft tolerance h6 k6 m6 n6 p6 s6
Bore tolerance P7 M7 K7 J7 H7 F7
Table5-1: Recommended assigned fits for bores with parallel key connection
Bore diameter
WARNING
Danger due to bursting of the coupling
If you exceed the maximum diameter of the finished bore, then this can cause the coupling
to burst in operation. There is a risk of fatal injury from flying fragments. If a coupling bursts
in an area at risk of explosion, then this can result in an explosion.
• Adhere to the maximum diameters specified.
The maximum diameters are listed in Section Speeds, geometry data and weights
(Page61)
Procedure
1. Remove the preservation and clean the coupling parts 1 (1) and/or 2 (2) to be machined.
2. Clamp the coupling according to the following figure.
NOTICE
Damage to the functional surface due to incorrect clamping
Never clamp the coupling part at the sealing surface of the O-rings.
3. Machine the finished bore D according to the following figure.
