User’s manual FlexGain Plex, V2
Version 1.3 51 from 99
where
PCM1, PCM2 are notations of Е1 streams.
To display the help information, enter <FRAME /H>.
Example:
PLEX2_01_PM>FRAME PCM1
--------------------------------------------------------------
PCM1 stream frame snapshot
--------------------------------------------------------------
ts 00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15
numbers 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
RX frame 00: DF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF
16: FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF
TX frame 00: 5F FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF
16: 55 FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF
--------------------------------------------------------------
PLEX2_01_PM>
Definitions:
Table 10. Description of the <FRAME> command.
Ts numbers Number of time slot (2 time slots are displayed at a time)
RX frame Content of time slots of the received E1 frame
TX frame Content of time slots of the transmitted E1 frame
<RESETG826> command.
The <RESETG826> command clears the ITU-T G.826 error performance parameter
counters.
Command syntax:
<RESETG826>
To display the help information, enter <RESETG826 /H>.
Example:
PLEX2_01_PM>RESETG826
G826 counters cleared.
PLEX2_01_PM>
<M[AIN]> command.
After the <M> command is entered the device displays exits the Performance
Management menu and returns to the main menu.
