Table 21. Correspondence of some values set by the <PORT Px NRT> command to the signal level in
absolute and relative units. (In this Table, the error in the signal value is no more than 5% when jumpers JP1,
JP3, JP5, JP7, JP9, JP10, JP11, JP12 are not set and jumpers JP2, JP4, JP6, JP8 are set in position 1-2).
Value set by the command Absolute level, mV Relative level, dB
0 Noise suppressor is off Noise suppressor is off
1 1 -58
10 10 -38
20 20 -32
30 30 -28
40 40 -26
50 50 -24
60 60 -22,2
70 70 -19,7
80 80 -18,7
90 90 -18,9
100 100 -18
110 110 -17
120 120 -16,2
130 130 -15,5
140 140 -14,9
150 150 -14,3
160 160 -13,7
170 170 -13,2
180 180 -12,8
190 190 -12,2
200 200 -11,8
