16 Outputs FLUXUS WW
UMFLUXUS_WWV1-1EN, 2018-02-28 111
16.1.1 Output range
Tab. 16.1: Configuration of the outputs
source item list item output
Measuring value actual measure physical quantity selected in the program branch Output Op-
tions
Flow flow, independently of the physical quantity selected in the program
branch Output Options
Quantity Q+ totalizer for the positive flow direction
* actual measure totalizer for the physical quantity selected in the program branch
Output Options
* Flow flow totalizer
Q- flow totalizer for the negative flow direction
* actual measure totalizer for the physical quantity selected in the program branch
Output Options
* Flow flow totalizer
ΣQ sum of the totalizers (positive and negative flow direction)
* actual measure totalizer for the physical quantity selected in the program branch
Output Options
* Flow flow totalizer
Limit R1 limit message (alarm output R1)
R2 limit message (alarm output R2)
R3 limit message (alarm output R3)
Impuls from abs(x) pulse without sign consideration
from x > 0 pulse for positive measured values
from x < 0 pulse for negative measured values
Miscellaneous c-Medium sound speed of the fluid
Concentration concentration of the fluid
SCNR ratio useful signal to correlated disturbance signal
Signal signal amplitude of a measuring channel
VariAmp standard deviation of the signal amplitude
Density density of the fluid
Pressure pressure of the fluid
When configuring an analog output, the output range is defined. Select a list item or other
range... to enter the output range manually.
If other range... is selected, enter the values Output MIN and Output MAX. Press
ENTER after each input.
This error message will be displayed if the output range is not min. 10 % of the max. output
range. The next possible value will be displayed. Repeat the input.
Example: I
MAX
- I
MIN
≥ 2 mA for a 4…20 mA current output
I1 Output range↕
4/20 mA
I1 Output MAX ↕
12.0 MINIMAL
