12.11 Diagnosis by means of the snap function
By means of the snap function it is possible to store measuring parameters which are useful for the evaluation of measur-
ing results or diagnostic purposes.
The snap function is activated in Special Funct.\SYSTEM settings\Signal snap\DSP-SignalSnap.
Snap memory settings
Delete snaps
Read Snaps
Activation of the snap function
In order to activate the snap function, press key during the measurement.
Select on to activate the snap function. Select off to deactivate the snap function. Press
ENTER.
Select Install Snap. Press ENTER.
Enter the number of the snap memory storage space. Press ENTER.
Activate or deactivate the auto-snap function. Press ENTER.
Activate or deactivate the snap ringbuffer. Press ENTER.
Select Clear Snaps. Press ENTER.
Select Snaps ->Rs232. Press ENTER.
DSP-SignalSnap
Install Snap
DSP-SignalSnap
Clear Snaps
DSP-SignalSnap
Snaps ->Rs232
To Next Page
