A Menu structure FLUXUS WW
UMFLUXUS_WWV1-1EN, 2018-02-28 125
Annex
A Menu structure
INIT-resis-
tant
Program branch Parameter
main menu: selection of the program branch Parameter
selection of a measuring channel (A, B) or a calculation channel (Y, Z)
This display will not be indicated if the transmitter has only one measuring
channel.
When a measuring channel is selected (A, B)
input of the outer pipe diameter
input of the pipe circumference
This display will only be indicated if Special Funct.\SYSTEM set-
tings\Dialogs/Menus\Pipe Circumfer. is activated and Outer
Diameter = 0 has been entered.
input of the pipe wall thickness
range: depends on the connected transducers
default: 3 mm
selection of the pipe material
input of the sound speed of the pipe material
range: 600…6 553.5 m/s
This display will only be indicated if Other Material is selected.
selection whether the pipe is lined
selection of the lining material
This display will only be indicated if Lining = yes is selected.
input of the sound speed of the lining material
range: 600…6 553.5 m/s
This display will only be indicated if Other Material is selected.
input of the liner thickness
range: 0...50 mm
default: 3 mm
input of the roughness of the inner pipe wall
range: 0…5 mm
default: 0.1 mm (for steel as pipe material)
input of the fluid temperature
default: 20 °C
>PAR< mea opt sf
Parameter
Parameter
for Channel A:
Outer Diameter
100.0 mm
Pipe Circumfer.
314.2 mm
Wall Thickness
3.0 mm
Pipe Material
Carbon Steel
c-Material
3230.0 m/s
Lining
no >YES<
Lining
Bitumen
c-Material
3200.0 m/s
Liner Thickness
3.0 mm
Roughness
0.4 mm
Medium Temperat.
20.0 C
