FLUXUS WW A Menu structure
126 UMFLUXUS_WWV1-1EN, 2018-02-28
input of the fluid pressure
range: 1...600 bar
This display will only be indicated if Special Funct.\SYSTEM set-
tings\Measuring\Gas-Measuring is activated or if Gas-Measur-
ing is deactivated and Special Funct.\SYSTEM settings\Dia-
logs/Menus is activated.
selection of the transducer type
This display will only be indicated if no or special transducers are con-
nected.
input of the length of an extension cable
When a calculation channel is selected (Y, Z)
Calculation channels are only available if the transmitter has more than one measuring channel.
display of the current calculation function
selection of the calculation function
Program branch Measuring
main menu: selection of the program branch Measuring
activation of the channels
This display will not be indicated if the transmitter has only one measuring
channel.
input of the measuring point number
This display will only be indicated if Output Options\Store
Meas.Data and/or Serial Output are activated.
activation/deactivation the flow profile correction
This display will only be indicated if Special Funct.\SYSTEM set-
tings\Measuring\Flow Velocity = uncorr. is selected.
input of the sound path number
display of the transducer distance to be adjusted between the inner edges
of the transducers
Program branch Output Options
main menu: selection of the program branch Output Options
selection of the channel whose output options are to be defined
selection of the physical quantity
INIT-resis-
tant
Fluid pressure
1.00 bar
Transducer Type
Standard
Additional cable
65.0 m
Calculation:
Y= A - B
>CH1< funct ch2
A - B
par >MEA< opt sf
Measuring
CHANN:>A< B Y Z
MEASUR - .
A:Meas.Point No.:
xxx (↑↓← )
A:PROFILE CORR.
>NO< yes
A: Sound Path
2 NUM
Transd. Distance
A:54 mm Reflex
par mea >OPT< sf
Output Options
Output Options
for Channel A:
Physic. Quant.
Volume flow
