A Menu structure PIOX R721
2021-09-01, UMPIOX_R721V1-3EN
102
Event triggers
Event trigger
Select Rx
Rx Enable
No Yes
Source item
Refractive index
Refractometer
Analysis Fluid properties Miscellaneous
Function
→ MAX (x>limit)
→ MIN (x<limit)
→ Within range
→ Out of range
→ ERR (x=fail)
Type
Non-hold Hold for a while Hold
Hold interval
[1] [2]
Range center Trigger value
Outputs Range width Hysteresis
Select an output
Glitch interval
… Enable
Failure delay
Yes
Source item
→ Event trigger
Output range
Idle state
Output info
Test signal
Legend
[1] if Within range or Out of range has been selected as function
[2] if MAX (x>limit), MIN (x<limit) or ERR (x=fail) has been
selected as function
1
2
