13 Outputs
13.1 Analog output
If the transmitter is equipped with outputs, they have to be configured. In principle, the measured value, the status value or
an event value can be transmitted via the different outputs.
• Select the menu Outputs.
• Press ENTER.
• Select the output to be configured.
The scroll list contains all available outputs.
• Press ENTER.
13.1.1 Enabling an output
If the output has to be used, it has to be enabled (here: Current I1)
• Select the output Current Ix (--).
• Press ENTER.
If the output has already been enabled, it is displayed as follows: Current I1 (√).
• Select Yes to enable an output or change the settings for an already enabled output.
• Select No to cancel the enabling and to return to the previous menu item.
• Press ENTER.
13.1.2 Assignment of a source item
One source item has to be assigned to each selected output.
• Select a source item whose measured value, status value or event value is to be transmitted to the output.
• Press ENTER.
Outputs
Select an output
Enable the output
Source item
Output
Measured values
Status values
Event values
see annex A
Outputs\Current I1(--)
Outputs\Current I1(--)
Outputs\Current I1\I1 Enable
Outputs\...\Source item
