17 Event trigger
PIOX R721
85
UMPIOX_F72xV1-3EN, 2021-09-01
17 Event trigger
It is possible to configure max. 4 independent event trigger
R1, R2, R3, R4.
The event triggers can be used, e.g., to:
– output information about the running measurement
– trigger special remote functions
• Select the menu Event trigger.
• Press ENTER.
• Select the
event trigger
.
If an event trigger has already been installed, it is displayed as follows: Rx(+).
• Select Yes to change the settings for an already assigned event trigger or to assign a new one.
• Select No to cancel the assignment and to return to the previous menu item.
• Press ENTER.
• Select the source item (physical quantity) for which a condition has to be defined.
Event trigger
Select Rx
Enable Rx
Source item
Define the function
see annex A
Event trigger\Rx(-)
Event trigger\Rx Enable
Event trigger\Rx Enable\Source item
Tab. 17.1: Source items
source item list item output
Refractometer Symmetry diagnostic values
Amplification
Amplitude
Quality
SNR
Transducer Sensor humidity
Transducer temp.
sensor values
Analysis Volume fraction physical quantities for analysis selected in the menu Parameters
Brix scale
Fluid properties Fluid temp. fluid temperature
Fluid density fluid density
Norm. density standardized density
Miscellaneous Custom. Input 1 measured values of input quantities (e.g., temperature, density) which
are not used for calculation
In the menu item Inputs\Assign inputs it is possible to assign
configured inputs to customized inputs.
For further information, see chapter 14.
Custom. Input 2
Custom. Input 3
Custom. Input 4
