19 Settings
PIOX R721 19.1 Dialogs and menus
91
UMPIOX_F72xV1-3EN, 2021-09-01
19 Settings
19.1 Dialogs and menus
• Select the menu item Miscellaneous\Dialogs/Menus.
• Press ENTER.
Measuring point number
• Select the menu item Measuring point no..
• Select Number if the measuring point is to be identified only by numbers. Select Text if the measuring point is to be
identified only by characters.
• Press ENTER.
Error delay
The error delay is the time after which an error value will be sent to an output if no valid measured values are available.
• Select the menu item Error value delay.
• Select Edit to enter an error delay. Select Damping if the damping factor is to be used as the error delay.
• Press ENTER.
Temperature correction
• Select the menu item Tx temperature offset.
• Select Yes to enable the input of a temperature correction.
• Press ENTER.
Display of the last value
• Select the menu item Display last value.
• Select Yes to display the last valid value.
If Yes is selected and no valid measured value can be displayed during the measurement, the last valid value will be
displayed. Behind this value an interrogation point will be displayed.
Switching off the display backlight
• Select Yes to activate the automatic switch-off.
• Press ENTER.
If the automatic switch-off of the display backlight is activated, the backlight is switched off after about 30 s. When
pressing a key or connecting a USB cable, the backlight is switched on again.
Miscellaneous\Dialogs/Menus
Miscellaneous\Dialogs/Menus\Measuring point no.
Miscellaneous\Dialogs/Menus\Error value delay
Miscellaneous\Dialogs/Menus\Tx temperature offset
Miscellaneous\Dialogs/Menus\Display last value
Miscellaneous\Dialogs/Menus\Light autom. off
