17 Event trigger
PIOX R721
2021-09-01, UMPIOX_F72xV1-3EN
86
Afterwards the properties of the event trigger are defined.
Definition of the switching condition
• Select the switching condition.
• Press ENTER.
Definition of the holding behavior
• Select the type of the holding behavior.
• Press ENTER.
Refractive index Refractive index measured refractive index in the fluid
Refractive index (Δ)
Norm. refrac. index
Tab. 17.2: Properties of the event trigger
property event trigger setting description
Function
(switching condition)
MAX (x>limit) The event trigger will switch if the measured value exceeds the upper
limit.
MIN (x<limit) The event trigger will switch if the measured value falls below the
lower limit.
Within range The event trigger will switch if the measured value is within the
defined range.
Out of range The event trigger will switch if the measured value is outside the
defined range.
ERR (x=fail) The event trigger will switch if a measurement is not possible.
Type
(holding behavior)
Non-hold If the switching condition is no longer met, the event trigger will return
to the idle state after approx. 1 s.
Hold The event trigger remains activated even if the switching condition is
no longer met.
Hold for a while The event trigger remains activated during a defined time even if the
switching condition is no longer met.
Event trigger\Rx Enable\Source item\...\Function
Event trigger\Rx Enable\Source item\...\Type
Tab. 17.1: Source items
source item list item output
