13 Outputs
13.1 Analog output PIOX R721
2021-09-01, UMPIOX_F72xV1-3EN
66
Depending on the selected source item, it is possible to output measured values, status values or event values.
Tab. 13.1: Configuration of the outputs
source item list item output
Refractometer Symmetry diagnostic values
Amplification
Amplitude
Quality
SNR
Transducer Sensor humidity
Transducer temp.
sensor values
Analysis Mass fraction physical quantities for analysis selected in the menu Parameters
Brix scale
Fluid properties Fluid temp.
Fluid density
Norm. density
Event trigger R1 limit message (Event trigger R1)
R2 limit message (Event trigger R2)
R3 limit message (Event trigger R3)
R4 limit message (Event trigger R4)
Miscellaneous Custom. Input 1 measured values of input quantities (e.g., temperature, density) which are
not used for calculation
In the menu item Inputs\Assign inputs it is possible to assign
configured inputs to customized inputs.
Custom. Input 2
Custom. Input 3
Custom. Input 4
Refractive index Refractive index
Norm. refrac. index
Refractive index (Δ)
Tab. 13.2: Output of measured values, status values or event values
source item measured value event value
value status
physical quantities Refractometer x x -
Analysis x x -
Fluid properties x x -
Miscellaneous
(Custom. Input 1...4)
x x -
Refractive index x x -
events Event trigger - - x
