9 Measurement
PIOX R721 9.1 Parameter input
53
UMPIOX_R721V1-3EN, 2021-09-01
9.1.3 Input of fluid parameters
The fluid parameters are entered for the selected measuring point.
Fluid
• Select the fluid from the scroll list.
• Press ENTER.
If the fluid is not in the scroll list, select the list item Other fluid.
Scale
• Select the scale (Brix, API) from the scroll list.
• Press ENTER.
This display will only be indicated if Other fluid is selected.
Fluid temperature
• Enter the fluid temperature at the operating point.
• Press ENTER.
Notice!
Customized fluids which are not included in the fluid scroll list can be read via the program FluxDiag. These fluids are
displayed in the fluid scroll list with an asterisk.
Notice!
The supplied fluid data remain stored even after an initialization of the transmitter.
Parameters\Fluid
Parameters\Fluid\Other fluid\Scale
Parameters\Fluid temp.
