7.2 Exiting the Programming and Calibration
With the Esc key the menu block can be left. Follow the diagram below to return to the operation from set-
up.
Display
Operation
[ item ]
For example [ ZrnG ]
Press Esc key to return to the main block.
[ block ]
For example [ bUıLd ]
Press Esc key to leave the set-up.
[ SAVE ]
Press Enter key to save the set-up.
Press Esc key to return to operation without saving.
