8. SERIAL DATA FORMATS
Continuous data and single line data format are described in this section. FT-107´s serial ports are suitable for
bi-directional communication. If you transmit ASCII codes for P(print), Z(zero), T(tare) or C(clear) to the one
of the serial ports, the indicator will act like the related keys are pressed.
Continuous-1 Data Format
The data format of the Continuous-1 data output:
Status
Indicated
Tare
STX
STA
STB
STC
D5
D4
D3
D2
D1
D0
D5
D4
D3
D2
D1
D0
CR
LF
CHK
The including of the status bytes STA, STB and STC are
Definition Table for Status A (STA)
Definition Table for Status B (STB)
Bits 0, 1 and 2
Bits 3 and 4
Bits 5,6
Bit 7
Bit 0
Bit 1
Bit 2
Bit 3
Bits 4,5
Bit 6
Bit 7
0
1
2
Decimal
point
3
4
Inc.
size
Always 1
X
1= Net
1= Weight negative
1= Error
1= Unstable
Always = 1
1=Zeroed with power on zero
X
1
0
0
XXXXXO
1
0
X 1
0
1
0
XXXXXX
0
1
X 2
1
1
0
XXXXX.X
1
1
X 5
0 = Gross
0 = Weight positive
0 = No Error
0 = Stable
0 = Not power on zeroed
0
0
1
XXXX.XX
1
0
1
XXX.XXX
0
1
1
XX.XXXX
Status C (STC) is always hex ‘30’.
Note: The weight data is represented with right aligned and the error messages (UNDER, OVER and A.OUT)
are represented with left aligned in indicated data field.
Continuous-2 Data Format
The data format of the Continuous-2 data output is;
[STX][STATUS][SIGN][INDICATED WEIGHT VALUE][UNIT][CR][LF][CHK]
Examples :
S+000123.4kg (weight is stable and 123.4)
D+000123.4kg (weight is dynamic and 123.4)
+ (Over load)
- (Under load)
O (ADC out error)
Checksum Calculation:
CHK (Checksum) = 0 – (STX + STATUS + ..... + LF)
Single Line Data Formats
Single line data output of the instrument is transmitted in the following data structure.
CN
Gross
Tare
Net
MSD
LSD
Spac e
MSD
LSD
Spac e
MSD
LSD
Spac e
MSD
LSD
LF
CR
9 chars
3
13 chars
3
13 chars
3
13 chars
1
1
Example:
Data output string for CN=21, Gross weight = 30.00 kg, Tare = 10.00kg and Net = 20.00kg will be;
CN: 21
G:
30.00kg
T:
1.000kg
N:
2.000kg
LF
CR
9 chars
3
13 chars
3
13 chars
3
13 chars
1
1
