10. TROUBLE SHOOTING
FT-107(S) weighing indicator had been designed as a very reliable and virtually error free instrument.
However, if an error occurs, do not attempt to repair the equipment before understanding what caused the
error. Note the problems you have with your instrument and the error messages shown on the display. Then
try to solve the problem according to the error table given below.
[ Over ] on the display
Load cell signal is higher than calibrated maximum level. Call
service for checking load cell and recalibration.
[ Under ] on the display
Load cell signal is lower than calibrated zero level. Call
service for checking load cell and recalibration.
[ E E E ] on the display
Zeroing at power on not possible. Check the scale.
The scale should be unloaded at power on.
[ AdCoUt ] on the display
Load cell signal is out of the ADC range.
- Check load cell connection.
- Check the load cell.
- Check the calibration.
- Change PCB.
Err 2
ADC communication error.
- Change PCB.
Err 34
Load cell signal is not increasing after loading the scale.
- Check the load cell connection.
- Check the load cell cable in the instrument.
- Change PCB.
Err 35
Load increase is small.
- Check the scale mechanic.
- Check the load cell connection.
- Increase the test weight.
- Change PCB.
Err 37
Scale is not stabile for calibration.
Err 70
Maximum scale capacity is more than 15000 kg or 30000 lbs.
- Reduce the capacity of the scale.
Err XX ( others )
- Disconnect power adaptor and battery.
- Connect battery and power adaptor in sequence
- Switch on the instrument if it is not.
- If there is any malfunction, change PCB or call service.
