7.5 Calibration
Please read this document carefully and select the parameter values which will fit your application before
programming the instrument
Warning: You cannot change the legally related parameter values and calibration after sealing the
instrument in legal usage. Be sure the proper adjustments you done before sealing the scale.
Before the calibration can be performed the capacity and resolution of the scale must be defined.
Calibration involves emptying the scale then placing a known test weight on an empty platform and allowing
the indicator to capture values for zero and span. Calibration is performed as;
7.5.1 [ CALıB ] Scale Parameters
You can reach the parameters to calibrate the scale in this block. Press Enter key to enter to this block or
press ► key to enter the next block or press Esc key to return to the operation (Page 36).
[ Unit: 0 ] Unit
O
kg
1
g
2
lb
3
oz
Press ▲ key to change the value. Press Enter key to enter the next item or press
Esc key to return to the main block.
[ rAnG: 0 ] Operation Range
O
Single range
1
Multi range
Press ▲ key to change the value. Press Enter key to enter the next item or press
Esc key to return to the main block.
[ P : 0 ] Decimal Point
O
XXXXXX
1
XXXXX.X
2
XXXX.XX
3
XXX.XXX
4
XX.XXXX
5
X.XXXXX
Press ▲ key to change the value. Press Enter key to enter the next item or press
Esc key to return to the main block.
If the scale is a multi-range scale two capacities and divisions, Cap1 / d1 and Cap2 / d2 will be shown
instead of single range CAP / d.
[ CAP ] Capacity
Press Enter key and enter the first scale range capacity by pressing navigation keys. Press
Enter to enter the next item. Maximum value can be 15000 kg or 30000 lb.
[ d : 1 ] Division
Select the first division of the scale from available ranges by pressing navigation keys.
Press Enter to go to the next item.
