Page 50 CWT Compact Touch Installation and Maintenanace Manual Issue 13
4.11 CWT Compact interconnections
This chapter aims to shows how each part of the terminal is connected to the
CPU board.
The drawings are available in a separate document: “CWT Compact Cable
Diagrams for AVE (2100-0009).pdf”
4.12 CPU board version 0501-E0150 Rev H
Note:
For earlier versions of the CPU board see earlier issues of this document
The CPU board consists of a main printed circuit board assembly. It contains a
32-bit 800 MHz processor with a 256 MB non-volatile flash memory used to store
the operating system (Windows CE) and a 512 MB RAM. The latter, including the
real-time clock, is backed up by a battery positioned on the CPU board.
Important:
This board requires Compact AVR AVE version 3.0.0.28 or later
The figure below shows the positions of connectors etc. The figure is followed by
a list of all connectors and their use.
