Page 60 CWT Compact Touch Installation and Maintenanace Manual Issue 13
Unless otherwise agreed, the customer is responsible for providing an
appropriate 12V battery. For CWT Compact terminals connected to the grid
power supply, a battery capacity of 17 Ah is required. Terminals equipped with a
solar cell panel require at least 45 Ah.
The customer is responsible for installing cables for terminals that will use the
grid power supply. When delivered, terminals are ready to be connected to the
power supply used at the installation site.
It is up to the customer to ensure that
the correct type of battery charger and fuses are used.
Note:
The maximum total power consumption depends on the configuration of the
terminal.
5.2 Installing the terminal
Due to its heavy weight the terminal is usually transported in two pieces to the
installation site where the pedestal is secured to a concrete base or floor before
the cabinet is mounted on top of the pedestal.
Provided there is an appropriate lifting device or a hand cart at hand, the entire
terminal can be installed as a complete unit.
In this chapter
• Mounting the pedestal in its foundation
• Mounting the cabinet on top of the pedestal
• Installing the battery
• Connecting to the mains power grid
• Installing a modem
• Loading paper in a GeBe printer
• Installing the coin box
5.2.1 Mounting the pedestal in its foundation
WARNING:
Lifting the pedestal, the cabinet, or the complete terminal, requires two or three
persons due to the heavy weights.
