Issue 13 CWT Compact Touch Installation and Maintenanace Manual Page 93
8.9.2 Cabinet & pedestal door replacement
The door is fastened to the cabinet with an upper and a lower hinge pin. A spring
helps pressing the pins into corresponding holes in the cabinet.
Note:
The procedure for the pedestal is the same as for the cabinet door replacement
8.9.2.1 Removal
Caution:
The weight of the door is approximately 15 kg.
1. Turn OFF the ticket terminal.
2. Disconnect all cables running between the door and the cabinet.
3. Ensure that the upper hinge pin’s locking screw (2 mm Allen key) is tightened.
4. Hold the door with a steady grip.
5. Loosen the lower hinge pin’s locking screw (2 mm Allen key) and push the
screw with the attached hinge pin up and out of grip with the cabinet. Lock
the hinge pin in this upper position.
6. Carefully pull the lower end of the door out and then lower the door to
disengage the upper hinge pin from the cabinet.
