Page 82 CWT Compact Touch Installation and Maintenanace Manual Issue 13
8.2 CPU board lithium cell replacement
Warning:
Lithium batteries can be dangerous because they can explode if short-circuited.
Handle batteries according to local laws and regulations.
8.2.1 Removal
Carefully lift the battery holder tongue a little when you remove the battery cell.
Warning:
Avoid using conductive objects due to the risk of short circuiting the battery.
8.2.2 Assembly
Install in reverse order.
8.3 Printer replacement
8.3.1 Gebe GTP4672 replacement
No specific actions needed
See Printer mounting for instruction how to dismount and mount the printer
• Remove any paper left in the printer
• disconnect all the cables
• unlock and lift of the printer shelf
• dismount the printer from its shell
• replace the new printer in reversed order
8.4 Coin unit replacement
8.4.1 Removal
1. Disconnect all cables from the coin unit. The number of cables depends on
the terminal model and configuration.
2. Loosen the two screw nuts, one at the top right side and one at the bottom of
the left side as shown below.
3. Keep the locking latch pulled (see arrow) while you lift and remove the coin
unit. Ensure that the black plastic coin slot insert in the door does not fall out.
