Issue 13 CWT Compact Touch Installation and Maintenanace Manual Page 53
Connector Function
J34 External Light
J35 External Pay unit e.g. SIX - Serial 1 – Com 3
J36 Solar Panel
J37 MDB
J38 Boot Mode
J39 Fuse Voltage
J40 Not mounted
J41 Colour display with LDVS and Backlight
J44 Not mounted
J45 Microphone
J47 JTAG imx53
J48 Not mounted
J49 Not mounted
SW8 On/Off Switch
U49 Modem Antenna
U57 SIM Card
4.13 Terminal measurements
Note:
The CWT Compact is available in two heights, the one presented in the figure
above (1616, 5 mm) and a shorter one (1516,5 mm).
