Page 70 CWT Compact Touch Installation and Maintenanace Manual Issue 13
Warning:
The coin box may be heavy depending on the amount of coins in it
6.1.2 Emptying the coin box
1. Turn the collection lock clockwise with the appropriate key. The same key
combination is usually used for all coin boxes.
2. Pull the emptying hatch out completely. This will empty the box of its contents
and activate the internal mechanism.
3. Push the emptying hatch in. The hatch can be pushed back in only if it has
previously been pulled out completely.
4. Turn the collection lock counter clockwise and remove the key.
6.1.3 Inserting the coin box
1. Insert an empty coin box.
2. Turn the opening knob counter clockwise to its vertical position. This locks the
box into position in the vault and opens the collection hatch.
Important:
If the knob is accidentally turned to the horizontal position at this point, the
box must be emptied as described in section 2 above before the knob can be
returned to the correct position.
3. Close the vault door. The opening knob must be in the vertical position for the
door to be closed.
6.2 Paper refill
Raise the print head and remove the remaining paper, if any.
Install new paper roll as described in section Loading paper in a GeBe printer.
