ROTADISK Pneumatic Actuator RD & RDF
Operating Manual – BA3002 EN
5 Installation
Page 37 of 79
5 Installation
5.1 Safety Information
To avoid personal injury and/or material damage, make sure that installation
work is performed only by qualified personnel with suitable personal protective
equipment (PPE) and suitable tools.
See chapter 2 Safety Information.
Danger of injury due to incorrect installation of the ROTADISK Pneumatic
Actuator on the valve!
Incorrect installation can lead to the valve not switching correctly. This
can cause severe injuries or even death.
Make sure, on installation, that the valve and the pneumatic
actuator have identical basic settings.
Danger of material damage due to incorrect installation of the ROTADISK Pneumatic
Actuator on the valve!
Incorrect installation can lead to the valve not switching correctly. This can cause
material damage.
Make sure, on installation, that the valve and the pneumatic actuator have identical
basic settings.
5.2 Preparations for ROTADISK Pneumatic Actuator Installation
Make the following preparations before installing the ROTADISK Pneumatic Actuator
on the valve or pipeline:
▪
Make sure that the load capacity of the pipeline is sufficient to support the ROTADISK
Pneumatic Actuator with valve and add-on components.
▪
Make sure that there is enough free space around the ROTADISK Pneumatic Actuator
with valve and add-on components to allow installation work without risks.
▪
Provide suitable installation equipment (e. g. lifting gear, installation device, torque
wrench, open-ended wrench, valve wrench, assembly grease).
▪
Determine suitable installation alternatives (direct installation or installation by means of
console).
