ROTADISK Pneumatic Actuator RD & RDF
Operating Manual – BA3002 EN
6 Commissioning
Page 40 of 79
6.2 Commissioning the ROTADISK Pneumatic Actuator
Observe the specifications in the manufacturer documentation (e.g. ball valve
operating manual) of the automatic valve components for commissioning work.
1. Check the pipework and all control lines for leakages.
2. Connect the power supply to the pneumatic actuator control components.
3. Connect the compressed air supply.
4. Check the function of optionally mounted auxiliary devices.
5. Switch the valve (e.g. ball valve) with the ROTADISK Pneumatic Actuator and
check whether
▪
the valve opens and closes correctly.
▪
the red dot on the yellow position indicator of the ROTADISK Pneumatic
Actuator points in longitudinal or flow direction when the valve is open
(opening of the ball parallel to flow direction).
▪
the red dot on the yellow position indicator of the ROTADISK Pneumatic
Actuator points transversely to the flow direction when the valve is closed
(opening of the ball is turned 90° to the flow direction) (see Figure 3, page 38.
✓ Commissioning is completed.
