ROTADISK Pneumatic Actuator RD & RDF
Operating Manual – BA3002 EN
11 Packing
Page 69 of 79
11.2 Packing the ROTADISK Pneumatic Actuator
The following prerequisites are satisfied:
The ROTADISK Pneumatic Actuator
▪
is not connected to and has been dismantled from the valve (e.g. ball valve).
▪
is free from dirt.
▪
is dry.
1. Select suitable packing to ensure that the ROTADISK Pneumatic Actuator reaches
its destination without damage.
Select suitable packing and observe intended destination, customer specifications,
applicable laws, load securing regulations, the properties of the transport goods (size,
weight, dimensions), protection requirements and means of transport (road, rail, air and
sea freight).
2. Protect the ROTADISK Pneumatic Actuator against tipping and slipping if
necessary.
3. Attach suitable and clearly legible transport symbols to the packing – especially
for sea freight – in accordance with ISO 780 and DIN 55402 if necessary.
Transport markings on the wooden crates are either stuck on or sprayed on with
weather-proof paint.
Possible transport symbols are:
This way up Delicate packed goods
Protect from wet Protect from heat (direct sunlight)
Centre of gravity Do not use hooks
Attach here
✓ Packing of the ROTADISK Pneumatic Actuator is completed.
