ROTADISK Pneumatic Actuator RD & RDF
Operating Manual – BA3002 EN
8 Repair
Page 49 of 79
23. Fit a new Q-ring [14] to the bottom side of the body flange and a new bearing
bush [15] into the bearing opening [13].
24. Grease the bearing opening [13] on the top body flange side.
Flowserve Flow Control GmbH recommends the low-temperature grease SAPPHIRE
Lo-Temp 2 made by ROCOL.
25. Fit a new greased Q-ring [14] on the top body flange side and a new bearing
bush [15] into the bearing opening [13].
[13]
[13]
[14]
[15]
[14]
[13]
[15]
