1672/1673 FC/1674 FC
Users Manual
12
Status
The status bar is information about the Tester. This bar shows:
Date and time: see Date/Time Format
d available memory, when more than 80 % is full, the icon is red
e FC device is connected
B shows a green checkmark when an FC mobile device is connected
Y Z a b battery usage, when <1 hr (Y) of charge remains the icon turns red
b[charging in-progress, icon turns green
Menu Bar
The menu bar shows on every screen (except the rotary and settings menu) and is a navigation
option. When a measurement screen is selected, the display shows the currently selected
measurement mode. Tap
J and M to toggle the screen view.
Project Status
The project status bar is information about the work in progress. This includes pass/fail status
with the limit settings. It also shows details about the selected form and the measurement test
type with the format:
NAME_OF_FORM/DISTRIBUTION_BOARD/CIRCUIT/TP
If no project is selected, the status bar shows: No project selected
The pass/fail indication is based on the limits set when you create or upload the form. Green
indicates Pass and red indicates Fail. For information on how to setup, see Limits.
