Measurements
This section has instructions for how to set up and use the Tester measurement functions.
Quick Save. Save test results from the function screen.
When you save a result, Quick Save assigns the results to a project consumer unit, circuit, or
test point.
1. Select a function.
2. Connect the leads.
3. Adjust settings according to the measurement requirements.
4. Push
T.
5. Push
N.
The quick save screen prompts you for a project code followed by consumer unit designation,
circuit designation, and test point designation.
Note
If the test is at the consumer unit, leave the circuit and test point designation blank. Or
if at the circuit, leave the test point blank.
Form Save. Save test results to a form created as part of a project.
Before you are able to use the Form Save function, see Form Mode for more information on
how to create a form.
1. In the form table, highlight the cell for the test function and measurement point to test.
2. Push
T.
3. Adjust the settings to the measurement.
4. Push
T.
5. Push
N.
Volts and Frequency Measurements
The volt mode measures the voltage across the leads. This mode shows all the voltages
between line pairs L-PE, L-N, and N-PE. The sub-result provides the frequency of the power
source.
