Preset Auto Test (1673 FC/1674 FC)
Auto Test is a sequence of tests set to run automatically in a selected order with one press of
T. You can customize the sequence with measurement settings. The Tester also has three
pre-set sequences for the most often used tests.
The results of the auto test sequence show in a table that updates each time a measurement
completes. See Figure 27.
If measurements are done one-by-one in an incorrect order, such as a test that requires no
voltage while there is still voltage on the line, the test goes to a waiting state for a corrective
action. An example is that you need to reset the RCD or apply voltage on the installation.
Figure 27. Auto Test Sequence Display
Preset 1 includes multiple tests:
 Line test (L-N)
 NoTrip Loop test (L-PE)
 RCD test:
 Ramp test (type A or type AC, 30 mA, 100 mA, 300 mA)
or
 Auto RCD test (type A or type AC, 30 mA, 100 mA)
 Insulation tests:
 L-PE, 50 V to 1000 V
 L-N, 50 V to 1000 V
 N-PE, 50 V to 1000 V
