Multifunction Tester
Input Terminals
23
The USB-C port supports data-communication with a PC and internal battery charging.
You can connect the Tester to a computer and download the test data to TruTest™ Data
Management Software. With the software, you can collect, organize, and display the test data
in a format that meets your needs. See Download Test Results for additional information on
using this port.
For more information about battery charging, see Power Adapter/Charger and Figure 1.
Table 8 . In p ut Termin a ls
Item Description
A
Blue Input N/L3/S (Neutral)
B
Green Input PE/L2/E (Protective Earth)
C
Red Input L/L1/H (Line)
D
USB-C Port
