Fluke 5700A Series User Manual

5700A/5720A Series II Calibrator
Service Manual
3-62
Table 3-26. 5720A AC Current 20 mA to 10A Accuracy Test Record
2A, 200 mA, 20 mA and 10A Test Record
Output
Current
Freq
A40 Shunt
AC-DC Diff
UUT Error
Display
Calculated
Error
Spec
± ppm
2A 40 Hz 320
2A 1 kHz 320
2A 5 kHz 510
2A 10 kHz 7100
200 mA 10 Hz 305
200 mA 20 Hz 200
200 mA 40 Hz 145
200 mA 1 kHz 145
200 mA 5 kHz 240
200 mA 10 kHz 1160
20 mA 10 Hz 305
20 mA 20 Hz 200
20 mA 40 Hz 150
20 mA 1 kHz 150
20 mA 5 kHz 255
20 mA 10 kHz 1400
10A (1) 40 Hz 417
10A (1) 1 kHz 417
10A (1) 5 kHz 888
10A (1) 10 kHz 3375
1: If a 5725A is attached.
