Calibration and Verification
Determining Test Limits for Other Calibration Intervals 3
3-63
Table 3-27. 5700A AC Current 20 mA to 10A Accuracy Test Record
2A, 200 mA, 20 mA and 10A Test Record (10A Only for 5725A)
Output
Current
Freq
A40 Shunt
AC-DC Diff
UUT Error
Display
Calculated
Error
Specs
±ppm
2A 40 Hz 670
2A 1 kHz 670
2A 5 kHz 800
2A 10 kHz 9100
200 mA 10 Hz 725
200 mA 20 Hz 400
200 mA 40 Hz 170
200 mA 1 kHz 170
200 mA 5 kHz 850
200 mA 10 kHz 2100
20 mA 10 Hz 725
20 mA 20 Hz 400
20 mA 40 Hz 160
20 mA 1 kHz 60
20 mA 5 kHz 850
20 mA 10 kHz 2100
10A (1) 40 Hz 417
10A (1) 1 kHz 417
10A (1) 5 kHz 888
10A (1) 10 kHz 3375
1: If a 5725 is attached.
