Troubleshooting
Component-level Troubleshooting 5
5-63
1 V
10 ms
F5-23.EPS
Figure 5-23. Waveform at Pin 6 of U13
1 V
10 ms
F5-24.EPS
Figure 5-24. Waveform at Pin 4 of U10
