Fluke 5700A Series User Manual

List of Replaceable Parts
Parts List
6
6-25
Table 6-7. A6 Wideband Ocillator PCA, Option -03
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
C1-8,C49-51 CAP,TA,4.7UF,+-20%,25V 807644 11
C9,C10 CAP,CER,2700PF,+-5%,50V,C0G 832303 2
C11 CAP,CER,15PF,+-20%,50V,C0G 697524 1
C12,C15,C16,
C18-25,C29-33,
C35-48,C52,
C57,C58,C60,
C61,C101,C103,
C105-107,C201,
C203,C205-207,
C301,C303, C305-
307,C401,
C403,C405-407,
C501,C503,C505-
507
CAP,POLYES,0.1UF,+-10%,50V 649913
649913
649913
649913
649913
649913
649913
649913
649913
649913
649913
649913
55
C13,C14 CAP,CER,0.047UF,+-10%,100V,X7R 844733 2
C17 CAP,POLYES,0.22UF,+-10%,50V 706028 1
C26-28 CAP,CER,0.01UF,+-10%,100V,X7R 557587 3
C34,C209-212 CAP,CER,82PF,+-2%,50V,C0G 714857 5
C53 CAP,CER,6800PF,+-5%,50V,C0G 542894 1
C54,C55,C102,
C108,C202,C208,
C302,C308,C402,
C408,C502,C508
CAP,POLYES,0.001UF,+-10%,50V 720938
720938
720938
720938
12
C56,C59 CAP,CER,33PF,+-5%,50V,C0G 714543 2
C62,C409-412 CAP,CER,390PF,+-2%,50V,C0G 820530 5
C109-112 CAP,CER,47PF,+-2%,100V,C0G 832295 4
C309-312 CAP,CER,180PF,+-2%,50V,C0G 820522 4
C509-512 CAP,CER,820PF,+-2%,50V,C0G 631002 4
CR1,CR2 DIODE,SI,VARACTOR,PIV=28V,500PF 2149283 2
CR102,CR103,
CR202,CR203,
CR302,CR303,
CR402,CR403,
CR502,CR503
*
*
*
*
*
DIODE,SI,SWICHING,PIN 334227
334227
334227
334227
334227
10
CR3-9 CR101,
CR201 CR301,
CR401 CR501
*
*
*
DIODE,SI,BV=75V,IO=150MA,500MW 659516
659516
659516
12
E2-5 JUMPER,WIRE,NONINSUL,0.200CTR 816090 4
E6 JUMPER,REC,2 POS,.100CTR,.025 757294 1
H6 LABEL,C-MOS INSTRUCTION 464016 1
H10 SCREW,PH,P,LOCK,SS,6-32,.750 376822 1
J1 CONN,COAX,SMB(M),PWB,RT ANG 353243 1
J6 HEADER,1 ROW,.100CTR,2 PIN 643916 1
L1-4,L7-12,L14,
L15
CHOKE,6TURN 320911
320911
12
L5 INDUCTOR,0.20UH,+-10%,400MHZ,SHLD 886809 1
L6 INDUCTOR,1500UH,+-5%,2.5MHZ,SHLD 806505 1
L16,L102,L104 INDUCTOR,1UH,+-5%,156MHZ,SHLD 806562 3
L101,L503 INDUCTOR,22UH,+-10%,38MHZ,SHLD 147843 2
L103 INDUCTOR,1.5UH,+-5%,128MHZ,SHLD 413856 1
L201 INDUCTOR,33UH,+-10%,33MHZ,SHLD 249086 1
L202,L204 INDUCTOR,2.2UH,+-5%,108MHZ,SHLD 806547 2
L203 INDUCTOR,3.3UH,+-10%,88MHZ,SHLD 174714 1
L301 INDUCTOR,82UH,+-10%,14MHZ,SHLD 542290 1
L302,L304 INDUCTOR,3.9UH,+-5%,84MHZ,SHLD 413864 2
L303 INDUCTOR,5.6UH,+-10%,69MHZ,SHLD 598219 1
L401 INDUCTOR,120UH,+-5%,11.2MHZ,SHLD 321042 1
L402,L404 INDUCTOR,8.2UH,+-5%,58MHZ,SHLD 806521 2
