Fluke 5700A Series User Manual

5700A/5720A Series II Calibrator
Service Manual
6-26
Table 6-7. A6 Wideband Ocillator PCA, Option -03 (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
L403 INDUCTOR,12UH,+-5%,47MHZ,SHLD 820720 1
L501 INDUCTOR,220UH,+-5%,9.4MHZ,SHLD 147835 1
L502,L504 INDUCTOR,15UH,+-5%,41MHZ,SHLD 806513 2
MP1 SHIELD, WIDEBAND OSCILLATOR, FRONT 775478 1
MP2 SHIELD, WIDEBAND OSCILLATOR, REAR 775486 1
MP5,MP11,MP12 CABLE ACCESSORY,CLAMP,ADHESIVE 838300 3
MP6,MP7 RIVET,S-TUB,OVAL,AL,.087,.343 838458 2
MP8,MP9 EJECTOR,PWB,NYLON 494724 2
MP10 CABLE, 75 OHM RF 761304 1
P101 CONNECTOR ,CONN,DIN41612,TYPE C,RT ANG,64 PIN 807800 1
Q2,Q3 TRANSISTOR,SI,NPN,SMALL SIGNAL 698241 2
Q4-7 * TRANSISTOR,SI,NPN,HI-FREQ,SMALL 659417 4
Q8,Q9,Q101,
Q105,Q201,Q205,
Q301,Q305,Q401,
Q405 Q501,Q505
*
*
*
*
TRANSISTOR,SI,N-DMOS FET,TO-72 394122
394122
394122
394122
12
Q102,Q202,Q302,
Q402,Q502
*
*
TRANSISTOR,SI,NPN,HI FREQ,TO-39 1590835 5
Q103,Q104,Q203,
Q204,Q303,Q304,
Q403,Q404,Q503,
Q504
*
*
*
*
TRANSISTOR,SI,NPN,SMALL SIGNAL 820407
820407
820407
820407
10
R3 RES,CF,300K,+-5%,0.25W 732818 1
R4,R5,R39,R41 RES,CF,12K,+-5%,0.25W 757799 4
R6,R87 RES,CF,100,+-5%,0.25W 810465 2
R7, R51 RES,MF,4.99K,+-1%,0.125W,100PPM 721548 2
R8,R25-27,R38,
R52,R66,R67,
R79,R80,R83
RES,CF,1K,+-5%,0.25W 780585
780585
780585
11
R9 RES,CF,20K,+-5%,0.25W 697110 1
R10 RES, 75K 851902 1
R11,R12 R15-18,
R21,R22
RES,CF,51,+-5%,0.25W 414540
414540
8
R13,R14,R19,
R20,R23,R24,
R70
RES,CF,270,+-5%,0.25W 348789
348789
348789
7
R28-30,R36,R81 RES,CF,2K,+-5%,0.25W 810457 5
R31 RES,MF,7.32K,+-1%,0.125W,100PPM 853630 1
R32,R53 RES,MF,1K,+-1%,0.125W,100PPM 816595 2
R33,R42,R43,
R46,R50,R54,
R60,R86,R103,
R203,R303,R403,
R503
RES,MF,49.9,+-1%,0.125W,100PPM 820266
820266
820266
820266
820266
13
R34,R57 RES,MF,30.1,+-1%,0.125W,100PPM 820563 2
R35,R55 RES,MF,3.32K,+-1%,0.125W,100PPM 817601 2
R37 RES,CF,3.9K.+-5%,0.25W 810416 1
R40,R74-78,R102,
R110,R111, R113-
116,R202,R210,
R211,R213-216,
R302,R310,R311,
R313,R402,R410,
R411,R413,R502,
R510,R511, R513
RES,CF,10K,+-5%,0.25W 697102
697102
697102
697102
697102
697102
697102
697102
32
R44 RES,CF,4.7K,+-5%,0.25W 721571 1
R45,R47 RES,MF,200,+-1%,0.125W,100PPM 820282 2
R48 RES,MF,866,+-1%,0.125W,50PPM 816603 1
R49 RES,MF,10K,+-1%,0.125W,100PPM 658914 1
R51 RES,MF,4.99K,+-1%,0.125W,100PPM 721548 1
R56 RES,CC,330,+-5%,0.5W 686789 1
