List of Replaceable Parts
Parts List
6
6-27
Table 6-7. A6 Wideband Ocillator PCA, Option -03 (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
R58,R112,R212,
R312,R412,R512
RES,MF,110,+-1%,0.125W,100PPM 820571
820571
6
R59 RES,MF,14.3K,+-1%,0.125W,100PPM 721803 1
R61 RES,MF,2.49K,+-1%,0.125W,100PPM 810523 1
R62,R64,R65,R69 RES,CC,680,+-5%,0.5W 687803 4
R63 RES,CF,200,+-5%,0.25W 810390 1
R68 RES,MF,1.62K,+-1%,0.125W,100PPM 772004 1
R71 RES,MF,75,+-1%,0.125W,100PPM 820241 1
R72,R73 RES,MF,6.65K,+-0.1%,0.125W,100PPM 772558 2
R82 RES,CF,6.2K,+-5%,0.25W 714337 1
R84,R85 RES,CF,240,+-5%,0.25W 830588 2
R101,R201,R301,
R401,R501
RES,CC,220,+-5%,0.5W 643442
643442
5
R104,R204,R304,
R404,R504
RES,MF,249,+-1%,0.5W,100PPM 241281
241281
5
R105,R205,R305,
R405,R505
RES,MF,100,+-1%,0.125W,100PPM 817627
817627
5
R106,R107,R206,
R207,R306,R307,
R406,R407,R506,
R507
RES,CF,130,+-5%,0.25W 817593
817593
817593
817593
10
R108,R208,R308,
R408,R508
RES,MF,523,+-1%,0.125W,100PPM 820274
820274
5
R109,R209,R309,
R409,R509
RES,MF,2.67K,+-1%,0.125W,100PPM 820290
820290
5
TP1-4,TP10-17 JUMPER,WIRE,NONINSUL,0.200CTR 816090 11
U1 * IC,CMOS,4-BIT PHASE LCKD LOOP 799452 1
U2 * IC,OP AMP,JFET INPUT,8 PIN DIP 472779 1
U3 * IC,ECL,VOLTAGE CONTROLLED OSCILLATOR 454975 1
U4 * IC,ECL,DUAL D M/S F/F,W/SET&RESET 454959 1
U5 * IC,ECL,4-BIT BINARY COUNTER,12MHZ 799460 1
U6 * IC,ECL,8-1 LINE MULTIPLEXER (MUX) 799510 1
U7,U10,U11 * IC,COMPARATOR,QUAD,14 PIN DIP 387233 3
U8 * IC,CMOS,BCD-DEC & BIN-OCTAL DC 473769 1
U9 * IC,PBLR,MONOLITHIC,DIFF. AMP 783738 1
U12,U13 * IC,ARRAY,5 TRANS,NPN,5 ISOLATE 380188 2
U14 * IC,CMOS,QUAD INPUT NOR GATE 811158 1
U15 * IC,COMPARATOR,HI-SPEED,14 PIN 647115 1
VR1,VR4 * ZENER,UNCOMP,5.1V,5%,20.0MA,0.5W 853700 2
VR2,VR3 * ZENER,UNCOMP,10.0V,5%,20.0MA,05W 473744 2
VR5 * ZENER,UNCOMP,6.2V,5%,200MA,5W 806802 1
Z1 RES,CERM,SIP,10 PIN,9 RES,10K,+-2% 414003 1
Z2 RES,CERM,SIP,6 PIN,5 RES,10K,+-2% 500876 1
