5700A/5720A Series II Calibrator
Service Manual
6-36
Table 6-10. A9 Ohms Cal PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
C1,C28,C29 C55 CAP,POLYES,0.1UF,+-10%,50V 649913 4
C2,C3,C32,C35 CAP,CER,1000PF,+-20%,100V,X7R 816181 4
C4,C5,C8,C10,
C14,C15,C31,
C37-43 C45
CAP,POLYES,0.22UF,+-5%,50V 747519
747519
747519
15
C6 CAP,CER,470PF,+-10%,50V,C0G 733071 1
C7,C9,C22 C23 CAP,TA,2.2UF,+-10%,35V 697433 4
C12,C13 CAP,CER,220PF,+-20%,50V,C0G 740654 2
C16,C17 CAP,CER,22PF,+-5%,50V,C0G 714550 2
C18,C33 CAP,TA,4.7UF,+-20%,25V 807644 2
C19,C24,C25 CAP,TA,10UF,+-20%,35V 816512 3
C20,C52 CAP,CER,0.22UF,+80-20%,50V,Z5U 649939 2
C21 CAP,CER,2700PF,+-5%,50V,C0G 832303 1
C26,C27 CAP,CER,1800PF,+-5%,50V,C0G 832717 2
C30 CAP,POLYPR,0.1UF,+-10%,160V 446781 1
C34,C51 CAP,CER,33PF,+-5%,50V,C0G 714543 2
C36 CAP,TA,47UF,+-20%,10V 733246 1
C48 CAP,POLYPR,0.47UF,+-10%,160V 446807 1
C53,C54 CAP,POLYES,1UF,+-10%,50V 733089 2
CR1-10 * DIODE,SI,BV=75V,IO=150MA,500MW 659516 10
H1-4 RIVET,S-TUB,OVAL,AL,.087,.343 838458 4
H5 SCREW,PH,P,LOCK,STL,6-32,.250 152140 1
K1-5,K10 K11,
K13 K15-18,K20,
K22-27,K31
RELAY,ARMATURE,2 FORM C,5V,LATCH 769307
769307
769307
20
K6-9,K12 K14,
K19,K21 K28-30
RELAY,ARMATURE,4 FORM C,5V,LATCH 715078
715078
11
L2-8 CHOKE,6TURN 320911 7
M4 SHIELD, OHMS CAL 775312 1
MP1,MP2 EJECTOR,PWB,NYLON 494724 2
MP3 SLEEV,PVC,.500ID,CLEAR 113761 1
MP4 SHIELD, HIGH VOLTAGE CONTROL 761197 1
MP6-17 SPACER,.156 RND,SOLUBLE,.062,.060 296319 12
P311,P312 CONN,DIN41612,TYPE C,RT ANG,64 PIN 807800 2
Q1 * TRANSISTOR,SI,BV=60V,65W,TO-22 386128 1
Q2-4 * TRANSISTOR,SI,VMOS,PWR,TO-237,UV10KM 640516 3
Q5 * TRANSISTOR,SI,PNP,40V,0.35W,TO-92 698233 1
Q6 * TRANSISTOR,SI,NPN,SMALL SIGNAL 698225 1
R1-3,R80 RES,CF,10K,+-5%,0.25W 697102 4
R4,R8,R13,R32,
R35,R39 R45
RES,CF,1K,+-5%,0.25W 780585
780585
7
R9,R10,R43 R44 RES,CF,47,+-5%,0.25W 822189 4
R11 RESISTOR A52R,RES,MOX,330,+-5%,1W,200PPM 689604 1
R12,R23 RES,CF,100K,+-5%,0.25W 658963 2
R14,R15 RES,CF,24,+-5%,0.25W 817528 2
R16 RES,MF,10K,+-0.1%,0.125W,100PPM 658955 1
R17 RES,MF,10.1K,+-0.1%,0.125W,100PPM 658955 1
R18 RES,MF,76.8K,+-0.1%,0.125W,50PPM 851332 1
R24,R31 RES,CF,22K,+-5%,0.25W 747535 2
R25 RESISTOR A52R,RES,MOX,150,+-5%,1W,200PPM 689612 1
R26,R46 RES,CF,100,+-5%,0.25W 810465 2
R27 RES,MF,10K,+-1%,0.125W,100PPM 658914 1
R29,R30 RES,CF,200,+-5%,0.25W 810390 2
R33 RES,CF,16K,+-5%,0.25W 714303 1
R41 RES. SET,1.0 OHM 0.04% 3PPM TC 824193 1
R42 RES. SET,1.9 OHM 0.04% 3PPM TC 824201 1
T1 TRANSFORMER, OHMS 2W COMP 802652 1
