Fluke 5700A Series User Manual

List of Replaceable Parts
Parts List
6
6-37
Table 6-10. A9 Ohms Cal PCA (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
TP1,TP2,TP5-20 JUMPER,WIRE,NONINSUL,0.200CTR 816090 18
U1-3 * IC,OP AMP,LO-OFFSET VOLTAGE,LO-NOISE 605980 3
U4 * IC,OP AMP,PRECISION,LOW NOISE 782920 1
U5 * IC,OP AMP,GEN PURPOSE,COMPEMSATED 402750 1
U6 * IC,BIPOLAR,REG PULSE WIDTH MODULATOR 811935 1
U7 * IC,OP AMP,CHOPPER STABLIZED,LOW NOISE 810952 1
U8,U9 * IC,OP AMP,LO-NOISE,8 PIN DIP 495051 2
U10 * IC,OP AMP,DUAL,JFET INPUT,8 PIN 854059 1
U11 * IC,CMOS,PROGRMBL PERIPHERAL INTERFACE 780650 1
U12 * IC,CMOS,BCD-DEC & BINRY-OCTAL DECODER 650689 1
U13 * IC,CMOS,3-8 LINE DCDR W/ENABLE 773036 1
U14-20 * IC,BIMOS,8 CHNL HI-VOLT DRVR W/LATCH 782912 7
U21 * IC,CMOS,8-1 LINE MUX/DEMUX ANALOG SW 836304 1
U22 * IC,CMOS,HEX INVERTER,UNBUFFERED 741199 1
VR1,VR2 *
ZENER 1N756A A52R,ZENER,UNCOMP,8.2V,5%,20.0MA,0.4W
386771 2
VR3 * ZENER,UNCOMP,3.3V,5%,20.0MA,0.4W 820423 1
Z1 * RNET,CERM,SIP,5700 LO V INST AMP 813659 1
Z2 * RNET,CERM,SIP,5700 LO V AMP GAIN 809368 1
Z3 RES,CERM,SIP,10 PIN,5 RES,10K,+-2% 529990 1
Z4 RES,CERM,SIP,6 PIN,5 RES,1K,+-2% 408310 1
Z5 RNET,MF,HERM,SIP,5700 LO V DIVIDER 915889 1
