Fluke 5700A Series User Manual

5700A/5720A Series II Calibrator
Service Manual
6-50
Table 6-15. A12 Oscillator Control PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
C1-4,C12 C14,
C16,C18 C48
CAP,TA,4.7UF,+-20%,25V 807644
807644
9
C8,C10 CAP,AL,2.2UF,+-20%,50V 769687 2
C21 CAP,CER,10PF,+-10%,3000V,C0G 817049 1
C22,C25 CAP,TA,330UF,+-20%,3V 385963 2
C23,C24 C36-
38,C44-47 C49,
C50,C56 C57,
C61,C64 C65,
C67,C68 C70-
72,C76-81
CAP,POLYES,0.22UF,+-5%,50V 747519
747519
747519
747519
747519
747519
27
C26,C29,C30,
C42, C60
CAP,POLYES,0.47UF,+-10%,50V 697409
697409
5
C27,C28,C31,
C43, C63
CAP,POLYES,0.047UF,+-10%,50V 820548
820548
5
C33,C58,C59 CAP,CER,120PF,+-5%,50V,C0G 721142 3
C34,C35,C86,
C87
CAP,AL,47UF,+-20%,50V,SOLV PROOF 822403
822403
4
C39,C53 CAP,CER,330PF,+-5%,50V,C0G 697441 2
C40,C41 CAP,TA,10UF,+-20%,25V 714774 2
C51,C52,C66 CAP,CER,82PF,+-2%,50V,C0G 714857 3
C54 CAP,CER,3.3PF,+0.25PF,100V,C0J 816678 1
C55 CAP,CER,6.8PF,+-0.25PF,50V,C0G 715243 1
C62 CAP,POLYES,1UF,+-10%,50V 733089 1
C69,C90,C91 CAP,POLYES,0.01UF,+-10%,50V 715037 3
C74 CAP,CER,3300PF,+-5%,50V,C0G 830612 1
C75,C88 CAP,CER,33PF,+-5%,50V,C0G 714543 2
C82,C85 CAP,POLYES,0.022UF,+-10%,50V 715268 2
C83 CAP,CER,150PF,+-10%,50V,X7R 682377 1
C84 CAP,POLYPR,0.47UF,+-10%,160V 446807 1
CR1-3 * DIODE,SI,BV=75V,IO=150MA,500MW 659516 3
CR4,CR5 * DIODE,SI,SCHOTTKY BARRIER,SMALL SIGNL 408815 2
CR6-8 * DIODE,SI,BV=75V,IO=150MA,500MW 203323 3
CR12-15 * DIODE,SI,BV=70V,500MW 851910 4
H4-7 RIVET,S-TUB,OVAL,AL,.087,.343 838458 4
H13 SCREW,PH,P,LOCK,STL,6-32,.250 152140 1
HS1 HEAT DIS,RAD,.54X1.25X.35,TO-8 808204 1
K1 RELAY,ARMATURE,4 FORM C,5V,LATCH 715078 1
K2-9 RELAY,ARMATURE,2 FORM C,5V,LATCH 769307 8
L1-4 CHOKE,6TURN 320911 4
MP8,MP9 EJECTOR,PWB,NYLON 494724 2
M12 OSCILLATOR THERMAL COVER 797696 1
MP10 SHIELD, HIGH VOLTAGE CONTROL 761197 1
MP14 SPACER,.375 RND,SOLUBLE,.10THK 837823 1
P501,P502 CONN,DIN41612,TYPE C,RT ANG,64 PIN 807800 2
Q1 * TRANSISTOR,SI,100V,10W,TO-202 943803 1
Q2 * TRANSISTOR,SI,BV=100V,10W,TO-202 943790 1
Q3 * TRANSITOR,SI,PNP,SMALL SIG,TO-92 851977 1
Q4 * TRANSISTOR,SI,NPN SMALL SIGNAL 853478 1
Q5,Q9,Q11 * TRANSISTOR,SI,N-JFET,TO-92 832162 3
Q6,Q7,Q12 Q18,
Q20
*
*
TRANSISTOR,SI,N-CHAN,TO-92,SWI 832139
832139
5
Q8,Q13 * TRANSITOR,SI,N-JFET,UHF/VHF US 851972 2
Q10 * TRANSISTOR,SI,P-MOS,ZENER PROTECTED 306142 1
Q14 * TRANSISTOR,SI,NMOS,1W,4 PIN DIVIDER 853692 1
Q19 * TRANSISTOR,SI,N-DMOS FET,TO-72 394122 1
R1,R2,R55 RES,CF,30K,+-5%,0.25W 368753 3
