Fluke 5700A Series User Manual

List of Replaceable Parts
Parts List
6
6-51
Table 6-15. A12 Oscillator Control PCA (cont)
Reference
Designator
Description
Fluke
Stock
No
Tot Qty Notes
R3 RES,MF,143K,+-1%,0.125W,100PPM 291336 1
R4,R12 RES,CF,3K,+-5%,0.25W 441527 2
R5,R13,R25 R48,
R52,R53 R68, R69
RES,CF,1K,+-5%,0.25W 343426
343426
343426
8
R6 RES,CF,750,+-5%,0.25W 810374 1
R7 RES,CF,200,+-5%,0.25W 810390 1
R8-10 RES,MF,113K,+-1%,0.125W,100PPM 291302 3
R11 RES,CF,20K,+-5%,0.25W 697110 1
R14 RES,CF,22K,+-5%,0.25W 348870 1
R15 RES,CF,5.1K,+-5%,0.25W 368712 1
R16 RES,CF,15,+-5%,0.25W 348755 1
R17,R39 RES,CF,510,+-5%,0.25W 441600 2
R18 RES,CF,47,+-5%,0.25W 822189 1
R19 RES,CF,10,+-5%,0.25W 807669 1
R20 RES,MF,301K,+-1%,0.125W,25PPM 379156 1
R21 RES,CF,2K,+-5%,0.25W 441469 1
R22,R24,R29, R66 RES,CF,100K,+-5%,0.25W 348920
348920
4
R23,R30,R33 RES,CF,100K,+-5%,0.25W 658963 3
R26 RES,MF,316K,+-1%,0.125W,100PPM 289496 1
R27,R28,R70 RES,CF,1K,+-5%,0.25W 780585 3
R31,R37,R45 RES,MF,866,+-0.1%,0.125W,50PPM 838441 3
R32 RES,CF,120,+-5%,0.25W 442293 1
R34 RES,MF,3.61K,+-0.25%,0.25W,100PPM 832394 1
R35,R36,R40, R41 RES,MF,649K,+-1%,0.125W,100PPM 375972
375972
4
R38,R42 RES,MF,357K,+-1%,0.125W,25PPM 312793 2
R43,R63-65 RES,CF,20K,+-5%,0.25W 441477 4
R44 RES,CF,2.2K,+-5%,0.25W 343400 1
R46 RES,CF,12K,+-5%,0.25W 348847 1
R47 RES,CF,560,+-5%,0.25W 385948 1
R49,R54,R56 RES,CF,10K,+-5%,0.25W 348839 3
R50 RES,CF,47,+-5%,0.25W 441592 1
R55 RESISTOR A52R,RES,CF,30K,+-5%,0.25W 368753 1
R57 RES,MF,60.4K,+-1%,0.125W,100PPM 291419 1
R58 RES,MF,1K,+-1%,0.125W,100PPM 168229 1
R59,R60 RES,MF,4.99K,+-1%,0.125W,100PPM 721548 2
R62 RES,CF,4.7K,+-5%,0.25W 348821 1
R67 RES,MF,562K,+-1%,0.125W,100PPM 757815 1
TP1-8 JUMPER,WIRE,NONINSUL,0.200CTR 816090 8
U1,U3 * IC,OP AMP,50MHZ,CURRENT FEEDBACK AMP 836262 2
U2,U7 * IC,OP AMP,HI-SLEW RATE,8 PIN DIP 386268 2
U5,U26 * IC,OP AMP,LO-OFFSET VOLTAGE,LO-NOISE 605980 2
U8 *
IC,ANALOG SWITCH,DG211,+-15V,175 OHMS,QUAD BILATERAL,DIP16
586735 1
U9 * IC,OP AMP,DUAL,JFET INPUT,8 PIN 495192 1
U10 * IC,CMOS,14BIT DAC,12BIT ACC,CUR OUT 773101 1
U11,U30,U31 * IC,OP AMP,PRECISION,LOW NOISE 782920 3
U12 * IC,OP AMP,DUAL,PRECISION MATCH 782375 1
U13 * IC,OP AMP,JFET INPUT,WIDE BAND 808105 1
U14,U16 OP AMP LT1220CST ON 12 PIN ADAPTER BOARD 1577442 2 1
U15 * IC,OP AMP,QUAD JFET INPUT,14 PIN 659748 1
U17 * IC,ARRAY,5 TRANS,NPN,3 ISO,2 DEFF CON 248906 1
U18 * IC,CMOS,8-1 LINE MUX/DEMUX ANALOG SW 836304 1
U20 * IC,CMOS,PROGRMBL PERIPHERAL INTERFACE 780650 1
U19 CMOS DG444 ,IC,CMOS,QUAD BILATERAL SWITCH 910708 1
U21,U22 * IC,COMPARATOR,QUAD,14 PIN DIP 387233 2
U23,U24 * IC,BIMOS,8 CHNL HI-VOLT DRVR W/LATCH 782912 2
