Fluke 5700A Series User Manual

5700A/5720A Series II Calibrator
Service Manual
6-52
Table 6-15. A12 Oscillator Control PCA (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
U25 * IC,VOLT REG,FIXED,+5 VOLTS,1.5 AMPS 428847 1
VR1,VR2 * ZENER,UNCOMP,10.0V,5%,12.5MA,0.4W 246611 2
VR3 * ZENER,UNCOMP,5.1V,5%,20.0MA,0.4W 159798 1
VR4 * ZENER,UNCOMP,6.8V,2%,175.0MA,5.0W 325845 1
VR5,VR6 * ZENER,UNCOMP,6.8V,5%,37.0MA,1.0W 454595 2
VR7,VR8 * ZENER,UNCOMP,5.1V,5%,20.0MA,0.5W 853700 2
Z1 * RNET,CERM,SIP,5700 LO V AMP GAIN 760686 1
Z2,Z4 * RNET,MF,POLY,SIP,8840 LO V DIVIDER 655811 2
Z3 RNET,MF,HERM,SIP,5700 LO V DIVIDER 760645 1
Z5 RES,CERM,DIP,14 PIN,7 RES,10K,+-2% 601911 1
Z6 RES,CERM,SIP,8 PIN,7 RES,1K,+-2% 414557 1
Z7,Z8 * RNET,CERM,SIP,5700 LO V DIVIDER 785105 2
Z9 RES,CERM,DIP,16 PIN,8 RES,5.1K,+-5% 544130 1
Z10 RES,CERM,SIP,8 PIN,4 RES,4.7K,+-2% 573881 1
1. U14, U16, part number 1577442 are assemblies

Fluke 5700A Series Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% non-condensing
Frequency Range	10 Hz to 1 MHz
Accuracy	Varies by function and range. See manufacturer's specifications for details.
Output Stability	Varies by function and range. See manufacturer's specifications for details.
Power Requirements	50 Hz to 60 Hz
