Fluke 5700A Series User Manual

List of Replaceable Parts
Parts List
6
6-55
Table 6-16. A13 Oscillator Output PCA (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
MP13-15 SPACER,.375 RND,SOLUBLE,.10THK 837823 3
P511,P512 CONN,DIN41612,TYPE C,RT ANG,64 PIN 807800 2
Q6 * TRANSISTOR,SI,N-JFET,TO-92 832162 1
Q7 * TRANSISTOR,SI,N-DMOS FET,TO-72 394122 1
Q8 * TRANSISTOR,SI,NPN,SM SIGNAL,HI 272930 1
Q9 * TRANSISTOR,SI,NPN,SMALL SIGNAL 698225 1
Q10,Q11 * TRANSISTOR,SI,100V,10W,TO-202 943803 2
Q13 * TRANSISTOR,SI,BV=115V,3W,TO-126 601242 1
Q14 * TRANSISTOR,SI,PNP,70V,400MA,TO-39 866769 1
Q15 * TRANSISTOR,SI,PNP,40V,0.35W,TO-92 698233 1
Q16,Q17 * TRANSISTOR,SI,BV=100V,10W,TO-202 943790 2
R1,R6,R43 R60,
R65
RES,MF,2K,+-1%,0.125W,100PPM 816629
816629
5
R2,R40,R64,R67,
R69,R72, R108-
110
RES,CF,1K,+-5%,0.25W 780585
780585
780585
9
R7,R9,R11,R18 RES,CF,200,+-5%,0.25W 810390 4
R12,R13,R83 RES,MF,4.99K,+-1%,0.125W,100PPM 721548 3
R19,R37,R50 RES,CF,10K,+-5%,0.25W 697102 5
R25 RES,CF,39K,+-5%,0.25W 912621 1
R28 RES,MF,1K,+-1%,0.125W,100PPM 816595 1
R29,R62,R68 RES,MF,10K,+-1%,0.125W,100PPM 658914 3
R32 RES,CF,20K,+-5%,0.25W 697110 1
R33,R38,R51,
R78
RES,CF,16K,+-5%,0.25W 714303
714303
4
R35,R36,R47,
R52,R53,R59,
R63,R74,R75,
R80-82,R107,
RES,CF,4.7K,+-5%,0.25W 721571
721571
721571
721571
13
R39,R54,R76 RES,CF,12K,+-5%,0.25W 757799 3
R41 RES,CF,100K,+-5%,0.25W 658963 1
R42 RES,MF,10.2K,+-1%,0.125W,100PPM 816611 1
R48 RES,CF,51K+-5%,0.25W 747550 1
R49 RES,CF,270,+-5%,0.25W 810424 1
R55,R77 RES,CF,24K,+-5%,0.25W 697599 2
R56 RES,MF,34.8K,+-0.1%,0.125W,50PPM 772582 1
R57 RES,CF,43K,+-5%,0.25W 821777 1
R58 RES,CF,47K,+-5%,0.25W 721787 1
R61,R66 RES,MF,7.87K,+-1%,0.125W,100PPM 810549 2
R71,R73 RES,CF,3K,+-5%,0.25W 810366 2
R84,R85 RES,CF,33K,+-5%,0.25W 733667 2
R87,R94 RES,CF,100,+-5%,0.25W 810465 2
R88 RES,CF,4.7,+-5%,0.25W 816637 1
R89,R90,R9, R98 RES,CF,10,+-5%,0.25W 807669 4
R99 RES,CF,2.7,+-5%,0.25W 442061 1
R92,R93,R95,
R96
RES,CF,3.9,+-5%,0.25W 810473
810473
4
R100,R101 RES,MF,30.1K,+-1%,0.125W,100PPM 772061 2
R111,R112 RES,CF,620,+-5%,0.25W 810408 2
S1 SWITCH,SLIDE,SPDT 477984 1
TP1-10 JUMPER,WIRE,NONINSUL,0.200CTR 816090 10
U2 * IC,VOLT REG,FIXED,-12 VOLTS,1.5 AMPS 381665 1
U3,U6,U9 * IC,OP AMP,JFET INPUT,WIDE BAND 808105 3
U5,U7 * RES NET HYBRID, TESTED 793885 2
U8,U29 * IC,OP AMP,HI-SLEW RATE,8 PIN DIP 386268 2
U10 * IC,MULTIPLIER/DIV,4 QUAD,10 MH,DIP 904714 1
