Fluke 5700A Series User Manual

5700A/5720A Series II Calibrator
Service Manual
6-56
Table 6-16. A13 Oscillator Output PCA (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
U11 * RES NET HYBRID, TESTED 793885 1
U12,U32,U33 * IC,CMOS,OCTL D F/F W/3-STATE,+EDG TRG 585364 3
U15,U16,U19 * IC,BPLR,FOUR-QUADRANT MULT,16 PIN DIP 343335 3
U17,U27 * IC,CMOS,DUAL 4-1 LINE MUX/DMUX ANL SW 429886 2
U18 * IC,OP AMP,JFET INPUT,8 PIN DIP 472779 1
U20 * IC,COMPARATOR,DUAL,LO-PWR,8 PIN 478354 1
U21 * IC,FTTL,QUAD 2 INPUT NAND GATE 654640 1
U22 * IC,FTTL,DUAL JK F/F,-EDG TRIG 781211 1
U23 * IC,COMPARATOR,DUAL,HI-SPEED,14 DIP 647123 1
U24 * IC,BIMOS,8 CHNL HI-VOLT DRVR W/LATCH 782912 1
U25 * IC,CMOS,8-1 LINE MUX/DEMUX ANALOG SW 836304 1
U26 * IC,CMOS,PROGRMBL PERIPHERAL INTERFACE 780650 1
U28 * IC,CMOS,DUAL 8 BIT DAC,CURRENT 722272 1
U31 * IC,OP AMP,DUAL,JFET INPUT,8 PIN 495192 1
VR3,VR4 * ZENER,UNCOMP,9.1V,5%,20MA,0.5W 853788 2
VR7 * ZENER,UNCOMP,8.2V,5%,20MA,0.4W 810309 1
Z1 RES,CERM,SIP,6 PIN,5 RES,39K,+-2% 831065 1
Z2 RES,CERM,DIP,14 PIN,7 RES,10K,+-2% 601911 1
Z3 RES,CERM,SIP,8 PIN,7 RES,1K,+-2% 414557 1
Z4,Z5 RES,CERM,SIP,8 PIN,4 RES,10K,+-2% 513309 2
Z6 RES,CERM,SIP,6 PIN,5 RES,3.6K,+-2% 478818 1

Fluke 5700A Series Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% non-condensing
Frequency Range	10 Hz to 1 MHz
Accuracy	Varies by function and range. See manufacturer's specifications for details.
Output Stability	Varies by function and range. See manufacturer's specifications for details.
Power Requirements	50 Hz to 60 Hz
