Fluke 5700A Series User Manual

5700A/5720A Series II Calibrator
Service Manual
6-60
Table 6-18. A14 High Voltage Control PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
C1 CAP,POLYES,0.72UF,+-20%,1300V 853929 1
C2 CAP,POLYES,0.1UF,+-20%,1400V 821512 1
C3,C4 CAP,AL,470UF,+-20%,16V,SOLV PROOF 772855 2
C5 CAP,POLYES,1UF,+-10%,50V 733089 1
C6,C7 CAP,TA,10UF,+-20%,35V 816512 2
C8,C9 CAP,AL,10UF,+-20%,63V,SOLV PROOF 816843 2
C10,C20,C24-32 CAP,POLYES,0.1UF,+-10%,50V 649913 11
C11-13 CAP,TA,22UF,+-20%,10V 658971 3
C14 CAP,CER,330PF,+-5%,50V,C0G 697441 1
C15 CAP,CER,120PF,+-5%,50V,C0G 721142 1
C17 CAP,POLYES,2200PF,+-10%,50V 832683 1
C18 CAP,TA,1UF,+-20%,35V 697417 1
C21,C22 CAP,CER,33PF,+-5%,50V,C0G 714543 2
C23 CAP,CER,1000PF,+-20%,50V,X7R 697458 1
C33 CAP,CER,27PF,+-2%,100V,C0G 816652 1
CR1-4 * DIODE,SI,HIGH VOLTAGE,PIV=2K,4OMA 851956 4
CR5 DIODE,SI,RECT,BRIDGE,BV=50V,IO=3A 586115 1
CR6-12 * DIODE,SI,BV=75V,IO=150MA,500MW 659516 7
H4-7 RIVET,S-TUB,OVAL,AL,.087,.343 838458 4
H8,H9,H11 SCREW,PH,P,LOCK,STL,6-32,.250 152140 3
J1 CONN,MATE-N-LOK,HEADER,14 PIN 845318 1
K1,K2,K4 K8,
K10,K11,K14
RELAY,ARMATURE,2 FORM C,5V 733063
733063
7
K3,K5,K6 K9,
K12,K013 K15,
K16
RELAY,ARMATURE,1 FORM A/1 FORM 831545
831545
831545
8
K7 RELAY,ARMATURE,2 FORM C,5V,LATCH 769307 1
L1 CHOKE,6TURN 320911 1
MP1,MP2 EJECTOR,PWB,NYLON 494724 2
MP3 SHIELD, HIGH VOLTAGE CONTROL 761197 1
MP5 CABLE ACCESS,TIE,5.50L,.10W,1.25 DIA 530360 1
MP8 HEAT DIS,PRESS ON,TO-5 418384 1
MP10-13 WASHER,FLAT,STL,.149,.375,.031 110270 4
P611,P612 CONN,DIN41612,TYPE C,RT ANG,64 PIN 807800 2
Q2 * TRANSISTOR,SI,NPN,SMALL SIGNAL 698225 1
Q3,Q4 * TRANSISTOR,SI,P-JFET,TO-92 852111 2
R1,R2 RES,CC,47,+-5%,0.5W 644259 2
R3-5 RES,CC,200K,+-5%,1W 686774 3
R6,R8 RES,MF,23.2,+-1%,0.5W,100PPM 200790 2
R7 RES,CF,22K,+-5%,0.25W 747535 1
R9,R12,R64 RES,CF,1.5M,+-5%,0.25W 649962 3
R10,R11 RES,CF,1.5M,+-5%,0.25W 649962 2
R13 RES,CF,9.1K,+-5%,0.25W 706663 1
R14,R15 RES,CF,620,+-5%,0.25W 810408 2
R17,R46,R55 RES,CF,100K,+-5%,0.25W 658963 3
R18 RES,CF,1K,+-5%,0.25W 780585 1
R19 RES,MF,162K,+-1%,0.125W,100PPM 817569 1
R20 RES,MF,412K,+-1%,0.125W,50PPM 714287 1
R21,R24,R33,
R34,R47,R56,
R68,R69
RES,CF,10K,+-5%,0.25W 697102
697102
697102
8
R22 RES,CC,3K,+-5%,0.5W 641115 1
R23 RES,CF,200K,+-5%,0.25W 681841 1
R25 RES,CF,750K,+-5%,0.25W 747543 1
R26,R44,R45 RES,MF,100K,+-1%,0.125W,100PPM 757807 3
R27,R29 RES,MF,36.5K,+-1%,0.125W,100PPM 820324 2

Fluke 5700A Series Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% non-condensing
Frequency Range	10 Hz to 1 MHz
Accuracy	Varies by function and range. See manufacturer's specifications for details.
Output Stability	Varies by function and range. See manufacturer's specifications for details.
Power Requirements	50 Hz to 60 Hz
