Fluke 5700A Series User Manual

List of Replaceable Parts
Parts List
6
6-61
Table 6-18. A14 High Voltage Control PCA (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
R28 RES,MF,20.5K,+-1%,0.125W,100PPM 655233 1
R30-32 RES,MF,18.2K,+-1%,0.125W,100PPM 756429 3
R35-39,R50,R52 RES,MF,196K,+-1%,0.125W,100PPM 769984 7
R40,R41 RES,MF,464K,+-1%,0.125W,100PPM 772020 2
R42 RES,CF,1.5K,+-5%,0.25W 810432 1
R43 RES,MF,301K,+-1%,0.125W,100PPM 655274 1
R54 RES,CF,2K,+-5%,0.25W 810457 1
R57,R58 RES,CF,750,+-5%,0.25W 810374 2
R59 RES,CF,16K,+-5%,0.25W 714303 1
R60,R61 RES,CF,20K,+-5%,0.25W 697110 2
R62,R63 RES,CF,3K,+-5%,0.25W 810366 2
R65,R66 RES,CF,10,+-5%,0.25W 807669 2
R67 RES,CF,3.9,+-5%,0.25W 810473 1
R70,R71 RES,CC,4.7M,+-5%,0.25W 543355 2
T1 TRANSFORMER, HIGH VOLTAGE 775288 1
TP1-6 JUMPER,WIRE,NONINSUL,0.200CTR 816090 6
U1 * IC,OP AMP,DUAL,LO OFFST,VOLT,LO-DRIFT 685164 1
U2 * IC,OP AMP,QUAD,JFET INPUT,14 PIN 483438 1
U3 * IC,OP AMP,SINGLE,HIGH VOLTAGE 782342 1
U4 * IC,CMOS,MONOSTABL/ASTABL MULTIVIBRATR 535575 1
U6,U7 * IC,CMOS,QUAD BILATERAL SWITCH 910708 2
U8 * IC,CMOS,HEX INVERTER,UNBUFFERED 741199 1
U9 * IC,CMOS,PROGRMBL PERIPHERAL INTERFACE 780650 1
U10-13 * IC,BIMOS,8 CHNL HI-VOLT DRVR W/LATCH 782912 4
U14 * IC,CMOS,8-1 LINE MUX/DEMUX ANALOG SW 836304 1
VR1 * ZENER,UNCOMP,6.8V,5%,20.0MA,0.4W 260695 1
VR2,VR3 * ZENER,TRANS SUPPRESSOR,400V,5% 845003 2
VR4,VR5 * ZENER,UNCOMP,16.0V,5%,15.5MA,1.0W 313221 2
VR6,VR7 * ZENER,UNCOMP,3.3V,5%,20.0MA,0.4W 820423 2
VR8 * ZENER,UNCOMP,18.0V,5%,7.0MA,0,4W 327973 1
Z1 RES,CERM,SIP,8 PIN,7 RES,10K,+-2% 412924 1

Fluke 5700A Series Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% non-condensing
Frequency Range	10 Hz to 1 MHz
Accuracy	Varies by function and range. See manufacturer's specifications for details.
Output Stability	Varies by function and range. See manufacturer's specifications for details.
Power Requirements	50 Hz to 60 Hz
