Fluke 5700A Series User Manual

5700A/5720A Series II Calibrator
Service Manual
6-66
Table 6-20. A16 Power Amplifier PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
C1,C2 CAP,CER,10PF,+-10%,3000V,C0G 817049 2
C3 CAP,MICA,560PF,+-5%,500V 170431 1
C4,C28 CAP,CER,0.02UF,+-20%,500V,Z5U 407403 2
C5,C75 CAP,POLYES,0.047UF,+-10%,50V 820548 2
C6,C23,C63 CAP,CER,22PF 817049 3
C7,C24,C43 CAP,CER,1000PF,+-20%,50V,X7R 697458 3
C8,C13,C16,C20,
C47,C49,C60,C61,
C68-71
CAP,POLYES,0.22UF,+-5%,50V 747519
747519
747519
12
C9,C21 CAP,TA,15UF,+-20%,20V 807610 2
C10,C25 CAP,TA,1UF,+-20%,35V 697417 2
C11 CAP,CER,22PF,+-2%,50V,C0G 714832 1
C12 CAP,CER,2000PF,+-5%,50V, C0G 832618 1
C15 CAP,CER,0.01UF,+80-20%,500V,Z5 816991 1
C17 CAP,CER,22PF,+-10%,1000V,C0G 817023 1
C18 CAP,CER,6.8PF,+-0.1PF,500V,C0J 485383 1
C19 CAP,CER,100PF,+-5%,50V,C0G 831495 1
C22 CAP,MICA,2PF,+-0.5PF,500V 175208 1
C26 CAP,CER,1000PF,+-20%,3000V,Z5U 832709 1
C27,C78,C79 CAP,AL,3.3UF,+30-20%,450V 782524 3
C31-34 CAP,AL,22UF,+-20%,35V 817056 4
C40 CAP,POLYES,1UF,+-10%,50V 733089 1
C41 CAP,POLYPR,0.15UF,+-10%,400V 557504 1
C42 CAP,CER,470PF,+-10%,50V,C0G 733071 1
C45 CAP,TA,2.2UF,+-10%,35V 697433 1
C48,C72 CAP,CER,1.2PF,+-0.25PF,50V,C0K 715235 2
C57 CAP,CER,100PF,+-10%,1000V,S3N 816983 1
C65,C67 CAP,TA,4.7UF,+-20%,25V 807644 2
C73 CAP,CER,0.05UF,+80-20%,500V,Z5 105676 1
C74 CAP,POLYES,0.1UF,+-10%,50V 649913 1
C80,C81 CAP,POLYES,0.47UF,+-10%,50V 697409 2
C82 CAP,CER,10PF,+-2%,50V,C0G 713875 1
CR1-5,CR7,CR10,
CR12-014,CR16,
CR20,CR21,CR23-
025,CR27,CR29-
31,CR61-67
*
*
*
*
*
DIODE,SI,BV=75V,IO=150MA,500MW 659516
659516
659516
659516
659516
27
CR8,CR9 DIODE,SI,100 PIV,1 AMP 887203 2
CR18,CR19 * DIODE,SI,BV=125V,IO=150MA,500 MW 844647 2
CR33,CR68,
CR69
*
*
DIODE,SI,N-JFET,CURRENT REG,IF 852116
852116
3
CR35-39 DIODE,SI,BV=200V,IO=200MA 876867 5
CR53 * DIODE,SI,N-JFET,CURRENT REG,IF 334839 1
H1,H2 SCREW,PH,P,LOCK,SS,6-32,.500 320051 2
H3,H4 SCREW,PH,P,LOCK,SS,6-32,.750 376822 2
H10,H48,H59,H60 SCREW,PH,P,LOCK,SS,6-32,.375 334458 4
H13-16 RIVET,S-TUB,OVAL,AL,.087,.343 838458 4
HR8 * POWER AMP DC HYBRID 775437 1
K1,K2 RELAY,ARMATURE,4 FORM C,5V,LATCH 715078 2
K3,K4 RELAY,ARMATURE,2 FORM C,5V,LATCCH 769307 2
K10,K11,K13-16 RELAY,ARMATURE,2 FORM C,5V 733063 6
K12,K17 RELAY,ARMATURE,2 FORM C,5VDC,HI IR 1278765 2
L1-3 CHOKE,6TURN 320911 3
L10 INDUCTOR,1.5UH,+-5%,128MHZ,SHLD 413856 1
L12 CHOKE,2TURN 417196 1
M17 OSCILLATOR THERMAL COVER 797696 1
MP4 MOLDED COVER, HYBRID, R-NET 775619 1
MP5-6 HEAT DISSIPATOR,DPAK,10 C/W,SM,.315,.900,.400 1599214 2
