Fluke 5700A Series User Manual

List of Replaceable Parts
Parts List
6
6-67
Table 6-20. A16 Power Amplifier PCA (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
MP7-8 HEAT DIS,PRESS ON,TO-5 418384 2
MP20-23 INSUL PT,TRANSISTOR MOUNT,DAP,TO-5 152207 4
MP41,MP42,
MP45-47
SCREW,PH,P,LOCK,STL,6-32,.250 152140
152140
5
MP43,MP44 EJECTOR,PWB,NYLON 494724 2
MP49 HEATSINK, POWER AMP 803007 1 1
MP50 SHIELD, HIGH VOLTAGE, REAR 791921 1
MP51-54 INSUL PT,TRANSISTOR,NYL,.4,.61 844837 4 1
MP55 THERMAL INSULATOR, POWER AMP 791988 1 1
MP56,MP57 POWER AMP CLAMP BAR 803015 2 1
MP58 RIVETED AIR DUCT ASSEMBLY 764506 1
P701,P702 CONN,DIN41612,TYPE C,RT ANG,64 PIN 807800 2
Q1,Q3 TRANSISTOR,SI,N-MOS,40W,500V,T0-220 782540 2 1
Q2 * TRANSITOR,SI,N-JFET,UHF/VHF US 851972 1
Q4,Q7,Q32 Q60,
Q62
*
*
TRANSISTOR,SI,NPN,SMALL SIGNAL 698225
698225
5
Q5 * TRANSISTOR,SI,NPN,ST1020,60V,500MA,1GHZ,3W,TO-39 1590835 1
Q6 * TRANSISTOR,SI,PNP,SMALL SIGNAL 844993 1
Q8 * TRANSISTOR,SI,N-DMOS FET,TO-72 394122 1
Q9,Q16,Q54 * TRANSISTOR,SI,NPN SMALL SIGNAL 853478 3
Q10 * TRANSISTOR,SI,PNP,70V,400MA,TO-39 866756 1
Q11 * TRANSISTOR,SI,PNP,SWITCHING,TO-92 831446 1
Q12,Q14 * MOSFET,SI,N,STD1NB80,800V,1A,20 OHMS,1.75W 1599223 2 1
Q13 * TRANSISTOR,SI,P-MOS,500V,TO-92 782508 1
Q15,Q17 * TRANSISTOR,SI,P-MOS,POWER,500V 782482 2 1
Q31 * TRANSISTOR,SI,VMOS,PWR,TO-237,VN10KM 640516 1
Q33,Q34 * TRANSISTOR,SI,N-JFET,SEL,TO-92 707703 2
Q35 * TRANSISTOR,SI,BV=60V,65W,TO-220 386128 1
Q38 * TRANSISTOR,SI,BV=40V,40W,TO-220 369660 1
Q39,Q40,Q50,
Q51,Q57,Q58
*
*
TRANSISTOR,SI,N-DMOS PWR FET,T0-92 782565
782565
6
Q61 * TRANSISTOR,SI,PNP,40V,0.35W,TO-92 698233 1
R1 RES,CF,9.1K,+-5%,0.25W 706663 1
R2,R18,R54,R56,
R89,R90,R134,
R135
RES,CF,10K,+-5%,0.25W 697102
697102
697102
8
R3,R4,R81-83 RES,MF,100K,+-0.1%,0.5W,50PPM 369371 5
R5 RES,MF,30.1K,+-1%,0.125W,100PPM 772061 1
R6 RES,CF,51K+-5%,0.25W 747550 1
R7 RES,MF,1.5M,+-1%,0.125W,100PPM 714998 1
R8,R86 RES,MF,10K,+-0.1%,0.125W,50PPM 733972 2
R9,R10,R16,R33,
R40,R50 R59,
R115,R148 R149
RES,MF,1K,+-1%,0.125W,100PPM 816595
816595
816595
10
R11,R12 RES,MF,16.5K,+-1%,0.5W,100PPM 162529 2
R13 RES,MF,17.4K,+-1%,0.5W,100PPM 247270 1
R14,R73,R137 RES,CF,43K,+-5%,0.25W 821777 3
R15,R19,R52,
R57
RES,CC,68K,+-10%,1W 686987 4
R17,R53 RES,MF,4.99K,+-1%,0.125W,100PPM 721548 2
R20,R23 RES,CF,3.9K.+-5%,0.25W 810416 2
R22,R109,R133 RES,CF,430,+-5%,0.25W 817577 3
R24,R138 RES,CF,200,+-5%,0.25W 810390 2
R25,R32 RES,CF,750,+-5%,0.25W 810374 2
R26,R126,R128 RES,CF,620,+-5%,0.25W 810408 3
R27 RES,CC,1K,+-5%,0.5W 687811 1
