5700A/5720A Series II Calibrator
Service Manual
6-68
Table 6-20. A16 Power Amplifier PCA (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
R28,R29,R34,
R47
RES,MF,499K,+-1%,0.125W,100PPM 714980
714980
4
R30 RES,CF,330,+-5%,0.25W 830596 1
R31 RES,CF,100K,+-5%,0.25W 658963 1
R35,R74,R139 RES,CF,20,+-5%,0.25W 810382 3
R36,R141,R151,
R152
RES,CF,47,+-5%,0.25W 822189
822189
4
R37 RES,CF,12K,+-5%,0.25W 757799 1
R38,R118 RES,CF,47K,+-5%,0.25W 721787 2
R41,R51,R55 RES,CC,200K,+-5%,1W 686774 3
R46,R108 R110-
113
RES,CF,100,+-5%,0.25W 810465
810465
6
R58 RES,CF,33,+-5%,0.25W 414524 1
R61 RES,CF,750K,+-5%,0.25W 747543 1
R84 RES,MF,22.1K,+-1%,0.125W,100PPM 655266 1
R85 RES,CC,27M,+-5%,0.25W 875257 1
R87 RES,MF,84.5,+-1%,0.125W,100PPM 236851 1
R88,R97,R98 RES,MF,10,+-1%,0.125W,100PPM 820399 3
R92 RES JUMPER,0.02,0.25W 682575 1
R116,R129 RES,CF,4.7K,+-5%,0.25W 721571 2
R117 RES,CF,24K,+-5%,0.25W 697599 1
R120 RES,CC,47,+-5%,0.5W 644259 1
R125 RES,CF,2K,+-5%,0.25W 810457 1
R132 RES,MF,20K,+-0.1%,0.25W,25PPM 810564 1
R142 RES,CF,200K,+-5%,0.25W 681841 1
R143 RES,CF,300K,+-5%,0.25W 732818 1
R144 RES,CF,1K,+-5%,0.25W 780585 1
R146,R147 RES,CF,2.4,+-5%,0.25W 348508 2
R150 RES,CF,15,+-5%,0.25W 348755 1
TP1-5,TP7-13,
TP16,TP17
JUMPER,WIRE,NONINSUL,0.200CTR 816090
816090
14
TP6 SOCKET,SINGLE,PWB,FOR 0.080 PIN 170480 1
TP14 SOCKET,SINGLE,PWB,FOR 0.080 PIN 149138 1
TP15 SOCKET,SINGLE,PWB,FOR 0.080 PIN 149120 1
U1 * IC,OP AMP,PRGRBL OUT CURRNT,8 PIN 418913 1
U2,U5 * IC,CMOS,QUAD BILATERAL SWITCH 910708 2
U4 * IC,OP AMP,HIGH SPEED,LOW NOISE 875815 1
U7 * IC,OP AMP,OPA132 1779200 1
U8 * IC,CMOS,HEX INVERTER 381848 1
U9 * IC,OP AMP,CHOPPER STABLIZED,8 PIN 831263 1
U10 * IC,BPLR,FAHRENHEIT TEMPERTURE 845156 1
VR6,VR11,VR19,
VR22 VR26,VR28
VR32
*
*
*
ZENER,UNCOMP,10.0V,5%,12.5MA,0.4W 810267
810267
810267
7
VR15 * ZENER,UNCOMP,18.0V,5%,7.0MA,0.4W 827973 1
VR18 * ZENER,UNCOMP,15.0V,5%,8.5MA,0.4W 266601 1
VR51,VR52,VR57,
VR58
*
*
ZENER,UNCOMP,6.8V,5%,20.0MA,0.4W 260695 4
VR61,VR62 * ZENER,UNCOMP,3.3V,5%,20.0MA,0.4W 820423 2
VR64 * ZENER,UNCOMP,24.0V,5%,20MA,0,4W 267807 1
VR65 * ZENER,UNCOMP,8.2V,5%,20MA,0.4W 386771 1
XU7 CONNECTOR, ADAPTER, SO9, 8-PIN DIP 1778899 1
Z1 * RNET,MF,HERM,SIP,5700 HI V DIVIDER 764399 1
1. Part number 665570 is an assembly consisting of part numbers 803007, 791988, 782482, 782540, 844837, 334458, 803015 and 320051
